Cold Forming Equipment

JBF Series Bolt Former

  • Available from 2D2B to 6D6B configurations
  • 3mm to 42mm Cutoff Diameters
  • 11mm to 480mm Cutoff Lengths
  • 3 transfer systems to choose from:
    • IS series pneumatic type straight across transfer (Sacma style)
    • JS series pneumatic type straight across transfer (Sakamura style)
    • NS series spring type open / close transfer (National style)
  • PKO in all stations
  • Powerful S-CAM bushing cutoff system
  • Motorized feed length, wire stopper, and kick out adjustment (optional)
  • Ramslide with over-arm design which allows for stability and long-lasting reliability
  • Aluminum alloy bushing for main crank

The ram, with an extended arm allows for excellent stability and assures accurate, straight line movement. Self detection of the P.K.O overload will automatically stop the machine. The ram is made of spherical graphite iron casting (JIS FCD 55)
K.O. length adjustment is quickly and easily performed by the hand wheel shown
Air clutch and braking system allows the flywheel to keep running when the machine is unloaded
Stopper length adjustment is quickly and easily performed by the hand wheel shown
PKO adjustment scale
Box type motorized wire straighteners offer a stable straightening process
A powerful cut-off mechanism with S-CAM is directly driven by the crankshaft and moves horizontally
Feed length adjustment is through a servomotor system controlled by a push button
Equipped with two feed rollers for smaller bolt formers
Open / Close type transfer fingers deftly and securely grip the blank
IS TYPE pneumatic transfer systems offers another option for high speed and stable transfer
JS TYPE pneumatic transfer systems offers another option for better clamping and stable transfer
Standard 3 Shaft Gear Box, 4/8 pole induction AC motor, direct transmission
